Sound for Every Space

The PowerCore DPA-220 amplifier with Dante Embedded Platform (DEP) technology sets a new standard for performance, size, durability and features – from one of the industry’s most trusted brands. PowerCore amplifiers are POE rated devices that require no external power supply, allowing you to put a rugged, compact audio amplifier anywhere there is an available Ethernet drop.

This rugged and compact Dante™ enabled PoE high-performance audio amplifier delivers up to 20W into a pair of 4-8Ω speakers or 40W into a single 4-8Ω speaker. The DPA-220 provides Digital Signal Processing (DSP) features for the audio path including volume control, equalization, mixing, limiting, compression, and other advanced processing algorithms. The DPA-220 also integrates speaker health monitoring which tracks and reports the voltage and current delivered to the attached loads in real-time.

The PowerCore DPA-220 is engineered from the ground up to deliver spectacular sound to a wide variety of environments from conference rooms to coffee shops. The DPA-220 bridges the gap between convenience and outstanding audio performance, making it an essential component for any location where sound matters.

Specifications:

• PoE++ (802.3bt, Type 3) Powered Device
• Dante or AES67 Compatibility
• 24-bit Audio at 48kHz or 96kHz Sample Rate
• 2x20W / 1x40W Output Power (4Ω, ≤0.1% THD+N) Noise Floor
• ≤75uVrms (A-Weighted)
• Total Harmonic Distortion + Noise: ≤0.09% (1W, 4Ω, 20-20kHz)
• Auxiliary Power Support: 24VDC to 48VDC
• Certified for installation directly in Plenum Spaces
• Custom Integration via SARCI API
• Dimensions: 131mm x 46mm x 39mm
